Series LRS-75 (75W) Packaging Box Part Status Active Type Enclosed Number of Outputs 1 Voltage – Input 85 ~ 264 VAC, 120 ~ 373 VDC Voltage – Output 1 5V Current – Output 1 14 A Power (Watts) 70W
Applications Household Appliances, ITE (Commercial)
Voltage – Isolation 4 kV Efficiency 86.5% Operating Temperature -30?C ~ 70?C (With Derating) Features
Adjustable Output, Universal Input Mounting Type
Chassis Mount Size / Dimension 3.90″ L x 3.82″ W x 1.18″ H (99.0mm x 97.0mm x 30.0mm) Approval Agency CB, CCC, CE, cURus, TUV Minimum Load Required No Base Product Number LRS-75
